FTIR Spectroscopy

£ 11,425.00 (ex. VAT) 1 in stock

Gasmet FT-IR Gas Analyser Spectrometer Model - DX4030 Lab

ITEM-30475

This Gasmet FT-IR Gas Analyser Spectrometer Model - DX4030 was removed from a university lab where it was surplus to requirement.

The unit powers up and we have run a hardware check.

Acceptable values for hardware parameters:

Cell temp: close to ambient temp

Cell pressure: close to ambient pressure

Source intensity: >50% (original =100%) - Unit showed 89%

Interf height: >3V when cell is filled with zero gas (original approx 5.5V - Unit showed 3.57V

Interf center: 2000...3000 point - unit showed 2483 points

Electronic temp: 0...50ºC - unit showed 21.43

Detector temp: -37ºC - Unit showed -37.08ºC

Ext detector temp: +25ºC - Unit showed 19.82ºC

Nothing seems out on the acceptable values for the hardware parameters.

We then ran the Zero Calibration check after flushing the air for 3 minutes.

The unit showed - Min: 115.0000 Max: 58825.0000

Acceptable values for Maximum background spectrum are >40 000 or >70% of original.

The system is in good cosmetic condition but has some minor marks from use.

It comes in Hardigg Storm Case with:-

2 x Gasmet Battery Units

Gasmet Software CD

Quantitech Dongle

Gasmet Dongle

Gasmet DX4030 Quick Reference Cards

2 x Black carry cases

RECERTIFIED ITEM

£ 11,065.00 (ex. VAT) 1 in stock

Gasmet FT-IR Gas Analyser Spectrometer Model - DX4030 Lab

ITEM-30474

This Gasmet FT-IR Gas Analyser Spectrometer Model - DX4030 was removed from a university lab where it was surplus to requirements.

We had the unit inspected and recertified by a qualified service engineer.

They have tested this FTIR spectrometer and it's in full working order with the power supply or with the supplied battery. The controller is communicating with the instrument via bluetooth without any issue. It scans and the spectrum is fine. It analyses the air contents and shows each component concentration. The system passes the internal calibration process.

Comes in Hardigg Storm Case with:-

Gasmet Battery Unit

Gasmet Software CD

Gasmet Dongle

Gasmet DX4030 Quick Reference Cards

ATEN Driver & Info Pac CD

2 x Black carry cases

Battery Charger power supply

£ 6,500.00 (ex. VAT) 1 in stock

Perkin Elmer Spectrum GX Fourier & AutoImage Microscope FT-IR System

ITEM-38261

Perkin Elmer Spectrum GX Fourier & AutoImage Microscope FT-IR System

This was removed from a university lab where it was surplus to requirements.

The unit has been serviced and is working, but signal-to-noise is failing due to the age of the instrument.

It is in good cosmetic condition with minor marks.

£ 6,075.00 (ex. VAT) 1 in stock

Shimadzu IRAffinity-1 FTIR Spectrophotometer with Software Lab

ITEM-36711

Shimadzu IRAffinity-1 FTIR Spectrophotometer with Software

This was removed from a university lab where it was surplus to requirements.

The unit powers up and the lab has confirmed it is in working order, though it has not been used for a few years.

It is in good cosmetic condition with marks from use.

It comes with manuals and software discs:-

Shimadzu IR Solution version 1.50

Shimadzu IR Solution version 1.50SU1

Shimadzu IRAffinity-1 User Systems Guide

Shimadzu IRPrestige-21 User Systems Guide

Shimadzu IRAffinity-1/IRPrestige-21/FTIR-84005 Operation Guide

Shimadzu IRPrestige-21/FTIR-84005 Operation Guide

RECERTIFIED ITEM

£ POA 1 in stock

Thermo Electron Corporation Nicolet 380 FT-IR & Centaurus Microscope Lab

ITEM-39987

This item is new in stock. Please enquire for further details.

£ 5,240.00 (ex. VAT) 1 in stock

Varian 7000 FT-IR Spectrometer with FTS 6000 Power Supply Lab

ITEM-36952

Varian 7000 FT-IR Spectrometer with FTS 6000 Power Supply

This was removed from a university lab where it was surplus to requirements.

The unit powers up but we were unable to test it further without the software.

It is in good cosmetic condition with marks from use.

Included are;

Varian Spectrometer

Model - 7000 FT-IR

SN - 46040-409

Varian Power Supply

Model - FTS 6000

SN - PS-0391-0806

£ 3,650.00 (ex. VAT) 1 in stock

Thermo Nicolet Avatar 360 FTIR System with PC & Software Lab

ITEM-17039

This Thermo Nicolet Avatar 360 FTIR System was removed from a university lab where it was surplus to requirements.

The lab assured us it was in working order prior to collection, but unfortunately, the Power supply was not supplied with the system, and is not included.

The PC powers on and has the following software on it.

Python 25

ARCGIS

MiniTab 15

Blue J

AsyMetrix.

The system is in reasonably good cosmetic condition but has marks from age and use.

SPARES/REPAIR ITEM

£ 2,000.00 (ex. VAT) 1 in stock

Varian 600 UMA FT-IR Microscope System with Varian 3100 FT-IR Faulty

ITEM-36397

Varian 600 UMA FT-IR Microscope System with Varian 3100 FT-IR

This was removed from a university lab where it was surplus to requirements.

The unit has been professionally serviced but was found to be faulty during the service. The instrument fails initialisation with the report of Laser failed. It was opened and checked, and the internal optics appear to be fine. The laser is on but sounds like it's pulsing. The diagnostics run and power supply is fine.

It is sold for spares/repairs.

Included are the following items;

2x WF 10x18

1x Standard 15x Objective with purge collar - no markings

1x Standard Objective - no markings

1x Prior Motorised Stage ES111

S/N: 54094

1x Prior Optiscan ES9XY

S/N: 32482

1x Prior Joystick CS152V2

S/N: 32779

1x Prior Joystick CS152DP

S/N: R036687

3x VGA cables with adapters

1x Reflector

2x Test Slides

1x Prior Motorised Stage Operating Instructions

1x Varian 600 UMA FT-IR Operating Manual

1x Varian 3100 FT-IR Operating Manual

1x Varian 3100 FT-IR Excalibur Series

S/N: 010-0241-1093

This item is in a good cosmetic condition and powered on without issue.

1x Dell Computer

S/N: JH1JY91

This item is in a good cosmetic condition and powered on without issue.

1x WSxM Scanning Probe Microscopy Software, Version 3.0

1x Varian FT-IR Software, Version 4.05.009

1x NEC Monitor MultiSync EA191M

S/N: 89122858TB

1x Ecopac Power 24V Supply SA60-24V

SPARES/REPAIR ITEM

£ 1,190.00 (ex. VAT) 1 in stock

Perkin Elmer Spectrum GX FT-IR System Lab Spares/Repairs

ITEM-26030

This Perkin Elmer Spectrum GX FT-IR System was removed from a university lab where it was surplus to requirements.

We had the instrument inspected by a service engineer who reported that the unit powers up, but the IR source does not power up and the window is moisture damaged. The beam splitter looks fine and the laser powers up.

There is a PC with the unit it has Spectrum Software program version 5.3. on it.

The unit also comes with the following:

1x Perkin Elmer Part

1x Thomas Pump

Model: 107CCD14TFFL-621

The unit powers up

1x RS-232 DE-19 Cable

3x RLT-GNP1000-02

It is sold for spares/repairs.

SPARES/REPAIR ITEM

£ 1,180.00 (ex. VAT) 1 in stock

Perkin Elmer FT-IR Spectrometer System Spectrum BX II Lab Spares/Repairs

ITEM-27567

This Perkin Elmer FT-IR Spectrometer System Spectrum BX II was removed from a university lab where it was surplus to requirements.

The unit has been professionally serviced and found to be non-functional. The sample area windows are badly damaged. They opened and found the beamsplitter damaged, and the internal desiccant indicates approx 90% humidity.

There is no possibility of running the instrument in its present condition.

It is sold for spares/repairs.

£ 475.00 (ex. VAT) 1 in stock

Smiths Detections DuraScope Attenuated Total Reflectance Lab

ITEM-30009

This Smiths Detections DuraScope was removed by a university lab where it was surplus to requirements.

The unit powers on and is in good cosmetic condition with only minor marks from use. We were unable to test it at our facility.

£ POA 1 in stock

Varian 660-IR FT-IR Spectrometer Lab

ITEM-41289

This item is new in stock. Please enquire for further details.

£ POA 1 in stock

IRAffinity-1S Fourier Transform Infrared Spectrophotometer

ITEM-41650

This item is new in stock. Please enquire for further details.
