FTIR Instruments
Items 1 to 12 of 12
£ 11,425.00 (ex. VAT) 1 in stock
Gasmet FT-IR Gas Analyser Spectrometer Model - DX4030 Lab
ITEM-30475
This Gasmet FT-IR Gas Analyser Spectrometer Model - DX4030 was removed from a university lab where it was surplus to requirement.
The unit powers up and we have run a hardware check.
Acceptable values for hardware parameters:
Cell temp: close to ambient temp
Cell pressure: close to ambient pressure
Source intensity: >50% (original =100%) - Unit showed 89%
Interf height: >3V when cell is filled with zero gas (original approx 5.5V - Unit showed 3.57V
Interf center: 2000...3000 point - unit showed 2483 points
Electronic temp: 0...50ºC - unit showed 21.43
Detector temp: -37ºC - Unit showed -37.08ºC
Ext detector temp: +25ºC - Unit showed 19.82ºC
Nothing seems out on the acceptable values for the hardware parameters.
We then ran the Zero Calibration check after flushing the air for 3 minutes.
The unit showed - Min: 115.0000 Max: 58825.0000
Acceptable values for Maximum background spectrum are >40 000 or >70% of original.
The system is in good cosmetic condition but has some minor marks from use.
It comes in Hardigg Storm Case with:-
2 x Gasmet Battery Units
Gasmet Software CD
Quantitech Dongle
Gasmet Dongle
Gasmet DX4030 Quick Reference Cards
2 x Black carry cases
RECERTIFIED ITEM
RECERTIFIED ITEM
£ 11,065.00 (ex. VAT) 1 in stock
Gasmet FT-IR Gas Analyser Spectrometer Model - DX4030 Lab
ITEM-30474
This Gasmet FT-IR Gas Analyser Spectrometer Model - DX4030 was removed from a university lab where it was surplus to requirements.
We had the unit inspected and recertified by a qualified service engineer.
They have tested this FTIR spectrometer and it's in full working order with the power supply or with the supplied battery. The controller is communicating with the instrument via bluetooth without any issue. It scans and the spectrum is fine. It analyses the air contents and shows each component concentration. The system passes the internal calibration process.
Comes in Hardigg Storm Case with:-
Gasmet Battery Unit
Gasmet Software CD
Gasmet Dongle
Gasmet DX4030 Quick Reference Cards
ATEN Driver & Info Pac CD
2 x Black carry cases
Battery Charger power supply
£ 6,500.00 (ex. VAT) 1 in stock
Perkin Elmer Spectrum GX Fourier & AutoImage Microscope FT-IR System
ITEM-38261
Perkin Elmer Spectrum GX Fourier & AutoImage Microscope FT-IR System
This was removed from a university lab where it was surplus to requirements.
The unit has been serviced and is working, but signal-to-noise is failing due to the age of the instrument.
It is in good cosmetic condition with minor marks.
£ 6,075.00 (ex. VAT) 1 in stock
Shimadzu IRAffinity-1 FTIR Spectrophotometer with Software Lab
ITEM-36711
Shimadzu IRAffinity-1 FTIR Spectrophotometer with Software
This was removed from a university lab where it was surplus to requirements.
The unit powers up and the lab has confirmed it is in working order, though it has not been used for a few years.
It is in good cosmetic condition with marks from use.
It comes with manuals and software discs:-
Shimadzu IR Solution version 1.50
Shimadzu IR Solution version 1.50SU1
Shimadzu IRAffinity-1 User Systems Guide
Shimadzu IRPrestige-21 User Systems Guide
Shimadzu IRAffinity-1/IRPrestige-21/FTIR-84005 Operation Guide
Shimadzu IRPrestige-21/FTIR-84005 Operation Guide
RECERTIFIED ITEM
RECERTIFIED ITEM
£ POA 1 in stock
Thermo Electron Corporation Nicolet 380 FT-IR & Centaurus Microscope Lab
ITEM-39987
This item is new in stock. Please enquire for further details.
£ 5,240.00 (ex. VAT) 1 in stock
Varian 7000 FT-IR Spectrometer with FTS 6000 Power Supply Lab
ITEM-36952
Varian 7000 FT-IR Spectrometer with FTS 6000 Power Supply
This was removed from a university lab where it was surplus to requirements.
The unit powers up but we were unable to test it further without the software.
It is in good cosmetic condition with marks from use.
Included are;
Varian Spectrometer
Model - 7000 FT-IR
SN - 46040-409
Varian Power Supply
Model - FTS 6000
SN - PS-0391-0806
£ 3,650.00 (ex. VAT) 1 in stock
Thermo Nicolet Avatar 360 FTIR System with PC & Software Lab
ITEM-17039
This Thermo Nicolet Avatar 360 FTIR System was removed from a university lab where it was surplus to requirements.
The lab assured us it was in working order prior to collection, but unfortunately, the Power supply was not supplied with the system, and is not included.
The PC powers on and has the following software on it.
Python 25
ARCGIS
MiniTab 15
Blue J
AsyMetrix.
The system is in reasonably good cosmetic condition but has marks from age and use.
SPARES/REPAIR ITEM
SPARES/REPAIR ITEM
£ 2,000.00 (ex. VAT) 1 in stock
Varian 600 UMA FT-IR Microscope System with Varian 3100 FT-IR Faulty
ITEM-36397
Varian 600 UMA FT-IR Microscope System with Varian 3100 FT-IR
This was removed from a university lab where it was surplus to requirements.
The unit has been professionally serviced but was found to be faulty during the service. The instrument fails initialisation with the report of Laser failed. It was opened and checked, and the internal optics appear to be fine. The laser is on but sounds like it's pulsing. The diagnostics run and power supply is fine.
It is sold for spares/repairs.
Included are the following items;
2x WF 10x18
1x Standard 15x Objective with purge collar - no markings
1x Standard Objective - no markings
1x Prior Motorised Stage ES111
S/N: 54094
1x Prior Optiscan ES9XY
S/N: 32482
1x Prior Joystick CS152V2
S/N: 32779
1x Prior Joystick CS152DP
S/N: R036687
3x VGA cables with adapters
1x Reflector
2x Test Slides
1x Prior Motorised Stage Operating Instructions
1x Varian 600 UMA FT-IR Operating Manual
1x Varian 3100 FT-IR Operating Manual
1x Varian 3100 FT-IR Excalibur Series
S/N: 010-0241-1093
This item is in a good cosmetic condition and powered on without issue.
1x Dell Computer
S/N: JH1JY91
This item is in a good cosmetic condition and powered on without issue.
1x WSxM Scanning Probe Microscopy Software, Version 3.0
1x Varian FT-IR Software, Version 4.05.009
1x NEC Monitor MultiSync EA191M
S/N: 89122858TB
1x Ecopac Power 24V Supply SA60-24V
SPARES/REPAIR ITEM
SPARES/REPAIR ITEM
£ 1,190.00 (ex. VAT) 1 in stock
Perkin Elmer Spectrum GX FT-IR System Lab Spares/Repairs
ITEM-26030
This Perkin Elmer Spectrum GX FT-IR System was removed from a university lab where it was surplus to requirements.
We had the instrument inspected by a service engineer who reported that the unit powers up, but the IR source does not power up and the window is moisture damaged. The beam splitter looks fine and the laser powers up.
There is a PC with the unit it has Spectrum Software program version 5.3. on it.
The unit also comes with the following:
1x Perkin Elmer Part
1x Thomas Pump
Model: 107CCD14TFFL-621
The unit powers up
1x RS-232 DE-19 Cable
3x RLT-GNP1000-02
It is sold for spares/repairs.
SPARES/REPAIR ITEM
SPARES/REPAIR ITEM
£ 1,180.00 (ex. VAT) 1 in stock
Perkin Elmer FT-IR Spectrometer System Spectrum BX II Lab Spares/Repairs
ITEM-27567
This Perkin Elmer FT-IR Spectrometer System Spectrum BX II was removed from a university lab where it was surplus to requirements.
The unit has been professionally serviced and found to be non-functional. The sample area windows are badly damaged. They opened and found the beamsplitter damaged, and the internal desiccant indicates approx 90% humidity.
There is no possibility of running the instrument in its present condition.
It is sold for spares/repairs.
£ POA 1 in stock
Varian 660-IR FT-IR Spectrometer Lab
ITEM-41289
This item is new in stock. Please enquire for further details.
£ POA 1 in stock
IRAffinity-1S Fourier Transform Infrared Spectrophotometer
ITEM-41650
This item is new in stock. Please enquire for further details.
Items 1 to 12 of 12
