Zeiss LSM880 Inverted Confocal Microscope with Airyscan

This item is sold on behalf of a client where it is surplus to requirements.

This system is in good cosmetic condition and was fully functional when decommissioned. It has been professionally packed in crates and stored for approximately 18 months following decommissioning from an active research environment. The system was maintained under a Zeiss service contract and remains fully supported by Zeiss until 1st October 2027, after which it will receive ‘best effort’ support.

The system was purchased in 2017.

The system comprises the following:

• Spectral detector 32 ch GaAsP PMT+ 2 PMTs
• Airyscan super resolution GaAsP detector with fast module for 4x faster imaging
• Bandpass emission filters for Airyscan
• Axio Observer 7 inverted microscope stand
• Transmitted light (T-PMT) detector
• Objectives: 10x/0.45 Air, 20x/0.8 Air, 40x/1.2 Water
• Excitation lasers: 405, 458, 488, 514, 561, 594, and 633 nm
• AOTF laser power controller
• HXP 120 widefield illuminator with epifluorescence filter cubes (DAPI/GFP/Cy3)
• Motorised X,Y,Z stage
• Z piezo stage WSB 500 with 10nm resolution
• Full incubation chamber with temperature and CO₂ control
• 100W Halogen lamp for transmitted light imaging
• Condensor LD 0.55 H/Ph1/2/3/DIC
• Dedicated PC running Zeiss Zen Black software (latest version at decommissioning), upgraded to Windows 10
• Electrical connection box, all associated leads and connectors
• Optical table not included
• Full specifications available on request

It is available for collection from Hertfordshire, UK, but we may be able to offer shipping for an additional fee. A site visit to inspect the equipment may be arranged for serious buyers.

The normal terms and conditions do not apply to this item. This item is non-returnable and non-refundable.

Zeiss LSM780 Confocal Microscope System Observer .Z1 with Zeiss Zen Software

This system was removed from a university lab where it was surplus to requirements.

It powers on and was reported to be in working order prior to removal.

The microscope can focus on slides, the environmental system operates, and the stage can be controlled via the joystick. CAN communication has been tested via the PC.

It is recommended that a Zeiss engineer completes the setup.

This system comprises:

• Zeiss Observer .Z1 Microscope with Scan IM 130x100 DC - 1mm motorized stage and two specimen holders
• Zeiss LSM T-PMT Transmitted Detection Module
• HAL 100 Halogen Lamp
• Objectives: C-APOCHROMAT 10x/0.45W, LD LCI Plan-APOCHROMAT 25x/0.8 1mm Korr DIC (UV) VIS-IR, C-APOCHROMAT 40x/1.2 W Korr UV-VIS-IR, Plan-APOCHROMAT 63x/1.40 Oil DIC, Plan-APOCHROMAT 100x/1.4 Oil DIC
• Two Zeiss Pl 10x/23 444036-9000 Eyepieces
• Zeiss LSM780 Scan Head
• Zeiss Main Control System (3Phase 16amp)
• Zeiss TFT LCD Touchscreen Controller
• Wienecke & Sinske JoyMach4 Joystick Stage Controller
• Zeiss Remote 1426-763
• Zeiss Safety Switch Box
• Lasos LSN 3001 and LGN7812 Laser PSUs with a Lasos RMC 7812 72 remote

• 1 x Zeiss LSM780 Scan Head with 5 x laser lines:

 1. Orange - 594nm

 2. 405nm

 3. Red

 4. Green

 5. Blue



• Pecon Incubator XLmulti S1 Stage Enclosure with Pecon/Zeiss Temp Module S and Heating Unit XLS
• Zeiss MCU 2008, Power Supply 232, Fc12 Definite Focus Controller with Definite Focus Unit
• Zeiss HXP120C Fluorescence Light Source with a non-functional Kubler Lamp Hour Timer
• HP PC with monitor, keyboard, mouse, Windows 10 OS, 8TB storage, various versions of Zeiss Zen Software (latest version 2.1 SP3), and a Zeiss dongle
• Zeiss Live View PC
• All necessary cables and manuals

Nikon Eclipse Ti-E Motorised Inverted Microscope System

This system was removed from a university laboratory where it was surplus to requirements.

All components are in good used cosmetic condition.

The system was set up and powered on successfully, excluding the laser components. The microscope connects reliably to the PC and is fully controllable via the installed Nikon NIS Elements software.

The Andor camera appears highly sensitive to the microscope’s halogen lamp. While all core features function correctly and there are no clear faults.

The previous owner stated it was in working order prior to decommissioning in 2022.

The system comprises the following:

PC & Software

• 1 x HP XW6600 Workstation PC
• Includes 2 x monitors, keyboard, and mouse
• Running Windows 7
• Nikon NIS Elements software (version 4.51.01, Build 1146, LO, 64-bit) installed
• Hasp USB key included
• All Windows and software passwords have been cleared

Microscope

• 1 x Nikon Eclipse Ti-E microscope body
• Fitted with:
• TI-DH Dia Pillar Illuminator 100W with D-LH/LC Halogen Lamp
• Nikon T-P2 DIC Polarizer
• Nikon TI-CT-E Condenser
• Motorised stage
• Nikon TI-ND6-PFS Motorised Nosepiece
• Sutter Instrument Smart Shutter
• Nikon TI-TD Eyepiece Tube B with 2 x Nikon CFI 10x/22 eyepieces
• Nikon TI-TIRF-E Motorised Illuminator Unit
• Nikon Hg100 Lamp
• Nikon TI-HUBC/A Hub Controller

Objectives

• Nikon Plan Fluor 10x/0.30 Ph1 DL ∞/1.2 WD 15.2 (No DIC Prism)
• Nikon S Plan Fluor ELWD 20x/0.45 Ph1 ADM ∞/0.2 (No DIC Prism)
• Nikon S Plan Fluor ELWD 40x/0.60 Ph=2 ADM ∞/0.2 WD 3.6–2.8 (No DIC Prism)
• Nikon Plan Fluor 40x/1.30 Oil DIC H/N2 ∞/0.17 WD 0.2 (40xII DIC Prism)
• Nikon APO TIRF 60x/1.49 Oil ∞/0.13–0.21 DIC N2 (60xI DIC Prism)
• Nikon APO TIRF 100x/1.49 Oil ∞/0.13–0.20 DIC N2 (100xI DIC Prism)

Filter Components

• 2 x Filter Turrets:
• Positions include: DAPI, GFPHQ, REPHQ, TIRF, ANALY, Empty
• One turret is fully empty
• Sutter Instrument LB101Q-686 Filter Unit with the following filters installed:
• EX403/12
• EX490/20
• EX555/28
• EX653/20
• Several additional positions marked Full or Empty
• DAPI (Ex)

Cameras

• 1 x Andor iXON+ DU-885K-CSO-#VP-500 Camera
• 1 x Hamamatsu EM-CCD ImagEM Digital Camera with controller
• (Untested; likely a previous system component retained as a spare)

Controllers & Accessories

• 1 x Nikon A1R System
• 1 x Nikon TI-PS100W Lamp PSU
• 1 x Nikon HB-10104AF 100W Lamp PSU (Run Time: 2622 hours)
• 1 x Nikon TI-S CON Controller
• 1 x Sutter Instrument LAMBDA 10-3 Filter Wheel Controller
• 1 x MCL Nano-Drive Controller
• 1 x Okolab Control Unit
• 1 x Okolab H201-T1 Chamber Blower
• 1 x Okolab Environmental Chamber (not fitted in photos)
• 3 x Stage inserts
• Various printed manuals

Laser System

Lasers are untested

• 2 x Nikon LU-LR Units
• 1 x Nikon C1-LU4 containing:
• Melles Griot 65ICS/S2669 – 640 Laser
• Melles Griot 56RCS/S2780 – 405 Laser
• Melles Griot IMA101040ALS Laser
• Melles Griot 85-YCA-010-040 Laser
• 1 x Nikon D-Eclipse C1 containing:
• Melles Griot 56RCS/S2780 Laser
• Coherent Sapphire 488 Laser
• Melles Griot 85-YCA-010-700 Laser

Leica CTR 6000 TCS SP5 Laser Scanning Confocal Microscope

This system was removed from a laboratory where it was surplus to requirements.

The system powers on, with all units functional, including the stage and light sources.

According to the previous owner, the system features a Leica SP5 confocal with 3 PMT and 2 hybrid detectors, along with an FCCS system that includes 2 SPAD detectors. The filters for the detectors are beginning to delaminate and will need replacing. The SP5 computer is relatively new and has been updated to Windows 10. A full environmental chamber for temperature and CO2 control is also included.

The system consists of:

• TCS SP5 Control Desk, DMI6000CS Microscope, and Scan Unit (Serial No. 510000038, Year: 2007)
• Leica CTR 6000 Controller (Serial No. 280210)
• Leica CMS Detection Unit (Part No. BS054407)
• Leica APD Detection (Serial No. 65031)
• Leica Scan Head/Trigger Box (Serial No. 0051)
• Leica Switch Console V3 (Serial No. 0028960)
• Leica Cooling Fan and Flexible Duct (Part No. 1531229001)
• Leica Mercury Lamp Box (Type 11307072071/BZ)
• LEJ Mercury Bulb Controller (Type ebq 100mc-L, Serial No. 06 2380802161, 217 hours bulb run time)
• Leica Stage Controller (Part No. 11505180)
• The Box polycarbonate microscope enclosure
• The Cube CB02A Enclosure Heater with probe (Serial No. 10585)
• The Brick Air Humidity and CO2 Regulator (Serial No. 10654)
• Gecomp PC running Windows XP Pro (Serial No. 071362)
• HP Z4 PC running Windows 10 (Serial No. CZC026C55L, Product No. 1JP11AV)
• 2 x NEC 1990SXi Monitors (Serial Nos. 6Z009731YB, 6Y008209YB)
• Cherry Keyboard (Model MY 3000 USB, Serial No. G0006934)
• HP KB-1469 Keyboard (Serial No. 803180-L31)
• 2 x HP Mice (Part Nos. 672651-001, 458407-002)

The microscope is fitted with five objectives:

• Leica 784 HCX PL APO 100x/1.4-0.7 oil cs
• Leica 510 HCX PL APO 63x/1.4-0.6 oil cs
• Leica 214 HCX PL APO 20x/0.70 1MM corr bl
• Leica 506251 HCX PL APO 40x/1.25-0.75 oil
• Leica 506279 HCX PL APO 63x/1.2 W corr cs

Additional components:

• Twin binocular eyepieces HC PLAN s 10x/125 M
• 7 x colour filter and mirror blocks, 2 x filter block covers
• 12 x stage parts
• 1 x humidity water cylinder for The Brick

Included Software & Manuals:

• Leica Software Discs: Confocal Software v. 2.585 (2x), LAS AF v. 2.73-9723, SP5 WS Premium Recovery, SP5 SP8 Standard G4 Recovery W10, SP5 Workstation Recovery
• 2 x copies of Windows XP Professional OS
• Manuals: Newport PR 50 compact high-speed rotation stage, Coherent Sapphire 488-20 & 410-10 OEM Laser, The Brick operating manual, The Cube 2 temperature controller manual

Olympus LV200F LuminoView Bioluminescence Microscope System

This system was removed from a university laboratory where it was surplus to requirements.

The Olympus LV200F is in good used cosmetic condition. It powers on with the camera displaying an output; however, an image could not be obtained due to the lack of suitable equipment, namely a chiller for the camera.

This system is in full working order but requires a chiller to be fully operational, as the camera needs it for cooling.

System Components:

• Olympus LV200 - LuminoView Bioluminescence Microscope

• Fujitsu Celcius Windows XP PC: Includes keyboard, monitor, and mouse. Installed software includes:
• Image J, Cell M Imaging Software
• HC Image-Live
• Total Commander version 9.0a
• Nero
• OBS system configuration

• A dongle for the software is also included.

• 2 x Installation CDs: IX2 and Cell M.

• Olympus MI-IBC CO2 Incubation System
• Model: MI-IBC-IF-2MM
• Serial No.: 429901895
• The plate carrier was warm, indicating functionality.

• Hamamatsu EM-CCD Digital Electron Multiplier Camera
• Model: C900-13

• Olympus IX2-UCB-2 Control Box: Includes an Olympus U-HSTR2 remote.

• Olympus LG-PS2-5 100w Light Guide Illumination System: Comes with LG-PS2-FL.

Also Includes:

• 5x Operating Manuals:

• Olympus LG-PS2-5 Light Guide Illumination System
• Olympus IX2-UCB-2 Control Box
• Olympus MI-IBC CO2 Incubation System
• Hamamatsu CCD Digital Electron Multiplier Camera
• Cell M imaging software

Palm Microbeam3 Laser Capture Microdissector with Zeiss Axiovert 200 Microscope

This system was removed from a university laboratory where it was surplus to requirements.

The previous owner stated that the system was in working prior to decommissioning. We recommend that it be re-commissioned by a Zeiss engineer before it is used again.

The system comprises the following:

• 1 x Zeiss Axiovert 200 Manual Inverted Microscope, fitted with:
• 1 x Zeiss HAL 100 Halogen Lamp
• 1 x Zeiss 1005-847 6-Position Condenser (H, Ph1, Ph2, Ph3, DIC, DIC)
• 1 x Zeiss Cap Mover
• 1 x Palm ST2-568-B Automated Stage (software-controlled) with 3x1.0 slide holder
• 1 x 6-Position Nosepiece fitted with objectives:
• Zeiss Fluar/Palm 5x/0.25 ∞/0.17
• Zeiss Fluar/Palm 20x/0.75 ∞/0.17
• Zeiss Plan-NEOFLUAR/Palm 100x/1.30 Oil ∞/0.17
• 1 x Zeiss 1005-827 Binocular Tube 45º/23 with pair of Carl Zeiss 1016-758 W-PI 10x/23 Eyepieces
• 1 x Zeiss 1064-364 5-Position Reflector Turret fitted with Laser, FITC, Rhod, and 2 empty positions
• 1 x Zeiss AxioCam ICc1 Camera
• Illumination and Accessories:
• 1 x Zeiss HBO100 Mercury Lamp with EQB100 PSU
• 1 x Ludl Filter Wheel FW 6 POS W/SH with Ludl MAC5000 Power Base
• Laser Capture Components:
• 1 x Palm Microbeam 3 System
• 1 x Palm Joystick Controller
• 1 x Palm Footswitch
• 1 x Zeiss CryLas Laser Controller
• 1 x Zeiss System Control Box
• Control & Software:
• 1 x HP Z800 PC running Windows 7, pre-installed with:
• Zeiss AxioVision 4.8.2
• Zeiss PALMRobo 4.5
• Zeiss licence dongle included
• Keyboard, monitor, and mouse included
• Additional Items:
• Original Zeiss AxioVision software disc
• Assorted manuals and spare parts
• All necessary connection cables

Thermo Scientific Cellomics Arrayscan VTI Liquid Handling Module w/ Software Lab

This system was removed from a university laboratory where it was surplus to requirements.

The system is in good cosmetic condition and powers up correctly. The software was launched, and the system initialized, but further testing could not be performed at our facility.

The system comprises the following:

• Thermo Scientific Cellomics Arrayscan VTI Main Unit

• Dell Precision Tower 5810 PC with keyboard, monitor, and mouse
• Operating System: Windows 7 Pro 64-Bit
• Installed Software: Thermo Cellomics HCS Studio - Version 6.6.1

• Brightfield Module

Zeiss Axioplan 2/LSM 5 Pascal Confocal Laser System

This system was removed from a university laboratory where it was surplus to requirements.

The Axioplan 2 microscope has been successfully controlled via the included Pascal software.

While the laser modules have not been fully tested, the software allows toggling of the laser control.

All components are in good used cosmetic condition.

The system comprises the following:

• Zeiss Axioplan 2ie MOT microscope stand, fitted with:
• Zeiss LSM 5 Pascal VarioTwo
• HBO 100 Mercury Lamp with ebq100 power supply
• 4 x Filter Cubes: DIC, DAPI, FITC, Rhod
• 2 x Zeiss 44 40 34 Pl 10x/25 Eyepieces
• Zeiss 1067-325 Axio Mechanical Rotating Stage
• Zeiss 1159-530 Condenser
• Zeiss 1058-431 Light Channel
• Zeiss 1095-490 Switching Mirror
• HAL 100 Halogen Lamp
• 6-position nosepiece with objectives:
• Zeiss Plan-NEOFLUAR 10x/0.3 ∞/0.17
• Zeiss Plan-NEOFLUAR 20x/0.50 ∞/0.17
• Zeiss Plan-NEOFLUAR 40x/1.3 Oil ∞/0.17
• Zeiss Plan-APOCHROMAT 63x/1.4 Oil Ph3 ∞/0.17

• Zeiss LSM 5 Pascal Laser Module, including:
• Lasos LGK 7786 P 543nm Laser (June 2011) with Lasos SAN 7460A power supply
• Lasos LGK 7812 ML04 450–530nm Laser (November 2014) with Lasos LGN 7812-01 power supply

• Zeiss LSM 5 Pascal Laser Module +, including:
• Lasos LGK 7628-1 633nm Laser (May 2002) with Lasos SAN 7460A power supply

• Computer & Software:
• Fujitsu Siemens Celsius PC with Windows XP (password removed), Pascal Software installed, and serial hardware dongle
• 2 x NEC monitors, keyboard & mouse
• AxioVision software CDs

• Zeiss Pascal 5 ECU Units:
• 1 x ECU tested and working with this system
• 1 x ECU marked 'DEAD 5v' (included untested as a spare)

• Spare PC:
• Fujitsu Siemens Celsius 670 (non-booting, Windows 2000) – included for spare parts

• Other:
• Isolation table is included
• Table pictured with lasers is not included

Thermo Scientific Cellomics Arrayscan VTI HCS System

This system was removed from a university laboratory where it was surplus to requirements.

The system is in good cosmetic condition and powers up correctly, and the AxioService system test on the internal microscope passed with no errors, indicating proper functionality. Further testing could not be conducted at our facility.

The system comprises the following:

• Zeiss microscope that was tested through the PC; however, the system's full operation was not tested due to its complexity.

• Orbitor RS Stacker Unit: Controlled successfully via the PC.

• Dell Precision Tower 5810 PC: Runs on Windows 7 Pro 64Bit and includes a keyboard, monitor, and mouse. - It has Thermo Cellomics HCS Studio Version 6.6.1 and Carl Zeiss AxioService installed.

• HP PC: Runs Thermo Cellomics HCS Studio Version 6.4.3.

• Brightfield Module.

Setting up this system may require assistance from a trained engineer.

Zeiss Axiovert 200M Confocal Microscope System with LSM510 META & Multi-Laser Setup

This system was removed from a university laboratory where it was surplus to requirements.

The previous owner confirmed it was in good working condition prior to removal.

The microscope connects to the PC and communicates successfully. The Meta software displays CAN errors on startup, which appear to be due to the lasers not being connected. Further testing was not possible without the lasers, but all indications suggest the system is otherwise functioning as intended.

The system is in good used cosmetic condition with typical signs of general use. It includes a comprehensive confocal setup featuring multiple laser modules, incubation controls, computing equipment, and imaging software.

The system comprises the following:

Zeiss Axiovert 200M Confocal Microscope, fitted with:

• Zeiss Plan-NEOFLUAR 20x/0.50.
• Zeiss Plan-NEOFLUAR 10x/0.30 ∞/0.17
• Zeiss 1095-490 Switching Mirror
• Zeiss 1058-431 Light Channel
• Zeiss 1039-685 HAL100 Halogen Lamp
• Zeiss 1007-980 HBO100 Mercury Lamp
• Zeiss 1005-847 LD Condenser 0.55 H, Ph1, Ph2, Ph3, DIC II, DIC III
• Zeiss 1005-834 Mechanical Stage
• Zeiss 1005-827 Binocular Tube 45º/23
• 2 x Zeiss 1016-758 W-PI 10x/23 Eyepieces

Laser Scanning & Illumination Components:

• Zeiss LSM510 META Module
• Carl Zeiss LSM 5 Laser Module 1018-382, including:
• Coherent Enterprise II Laser with ENTCII-653 Controller (October 1997)
• Coherent LASERPURE 5 LP-5I Cooling System with hoses
• Lasos LGK 7812 ML4
• Lasos LGK 7628-1 (October 2005)
• Lasos LGK 7786 P (March 2010)
• Lasos LGN3000 PSU
• Zeiss AIM-System 2101000343 ECU
• ebq100 Power Supply Unit

Environmental Control:

• Solent Scientific Incubation Chamber
• Solent Scientific Heater & Controller

Computing & Software:

• Fujitsu Siemens Celsius 600 PC (Windows 2000, passwords removed), with:
• Carl Zeiss AxioSet
• Carl Zeiss AIM – LSM510 Version 3.2SP2
• HP Compaq DC7600 PC (no key software or PCI cards)
• 2 x NEC monitors, mouse, and keyboard
• Manuals and software for most components

Additional:

• Various connection cables
• Small equipment table (included)

Philips XL30SEM Environmental Scanning Electron Microscope ESEM

This item was removed from a university where it was surplus to requirement.

The system was in working order about 5 years ago, but has since required a new PC and has not been used.

There is no PC or Software included with this system.

It is in good cosmetic condition, with minor marks from use.

Item supplied with:

• BOC EDWARDS Turbomolecular Pump.

Type: B753-01-991.

Serial No: 016917679.

• Sony Video Graphic Printer.

Type: UP-895CE.

Serial No: 58728.

• High Temperature Stage Controller.

Type: 300-430-000.

Serial No: 020501.

• Philips Manual User Interface.

Type: 20445-C.

Serial No: 014203.

• NEC Multisync Monitor

Type: LCD1850E

Serial No: 202107890

• Caron Model: 2050W

Serial No: 091701-2915-03.

• Thermoelectric Stage Controller.

Type: 300-058-000.

Serial No: 011013.

Zeiss Axio AX10 Imager .D2 Microscope System with AmScope Camera, Multiple Objectives, and Lenovo Laptop

This system was removed from a university laboratory where it was surplus to requirements.

It is in good cosmetic condition and fully operational, complete with a Lenovo ThinkPad T14 Gen1 laptop that runs the AmScope camera software.

User log-in information is available on request.

Includes:

• Zeiss Axio AX10 Imager .D2 stand
• Zeiss 426114 60N-C 1" 1.0x C-Mount camera adapter
• AmScope MU1000-HS 10MP APTINA Colour CMOS USB Camera
• Zeiss 125503-9901 nosepiece
• Two Zeiss 444034-9000 eyepieces

• 10 Position Reflector loaded with 9 cubes:
• DAPI
• FL EC P&C 424931
• Cy3
• FCy3.5v1 SP-103 C32515 1046-281
• Cy5
• Aqua v2 31036 C32514
• F/TR 51006 C109220
• Cy5.5 SP-105 C32516
• Red Green 424931

• 7 Position Objective Turret fitted with:
• Zeiss ACHROPLAN 10x/0,25 ∞/-
• Zeiss Plan-APOCHROMAT 20x/0,8 ∞/0,17
• Zeiss EC Plan-NEOFLUAR 40x/1,3 Oil ∞/0,17
• Zeiss EC Plan-NEOFLUAR 63x/1,25 Oil ∞/0,17
• Zeiss Plan-NEOFLUAR 100x/1,30 Oil ∞/0,17
• Wetzlar EK 75x50 Axio Imager Manual Stage
• Zeiss 44 72 15 Halogen Lamp
• EXFO X-Cite 120 Lamp with EXFO 805-00038 Light Guide
• Lenovo ThinkPad T14 Gen1 laptop running the AmScope camera software

Model: AX10 Imager .D2

Serial No.: [serial number]

Zeiss Axio AX10 Imager .Z2 System, 100x/63x/40x/20x/10x Software AmScope PC Lab

This system was removed from a university lab where it was surplus to requirement.

It is in good cosmetic condition and in working order with use of the AmScope Software.

Includes:

• 1 x Zeiss Axio Imager .Z2 stand, fitted with:
• 1 x Zeiss 426114 60N-C 1" 1.0x C-Mount camera adapter.
• 1 x AmScope MU1000-HS 10MP APTINA Colour CMOS USB Camera, which can be mounted on the top or side with the included adapter.
• 1 x Zeiss 125503-9901 nosepiece.
• 2 x Zeiss 444034-9000 eyepieces.
• 1 x 10 Position Reflector loaded with 7 cubes (DAPI, Cy3, TxR, FITC, Cy5, Aqua, Red Green; three positions empty).

• 1 x 7 Position Objective Turret fitted with 5 objectives:
• 1 x Zeiss Plan-APOCHROMAT 10x/0.45, ∞/0.17, 420640-9900.
• 1 x Zeiss Plan-APOCHROMAT 20x/0.8, ∞/0.17, 420650-9901.
• 1 x Zeiss Plan-APOCHROMAT 40x/1.4 Oil DIC (UV) VIS-IR, ∞0.17, 420762-9900.
• 1 x Zeiss Plan-APOCHROMAT 63x/1.4 Oil, ∞/0.17, 420780-9900.
• 1 x Zeiss Plan-APOCHROMAT 100x/1.4 Oil, ∞/0.17, 420790-9901.

• 1 x Zeiss 432014 Manual Stage.
• 1 x Zeiss 424206-9901-000 Achromatic Condenser 0.8 HDIC.
• 1 x Zeiss 423000-9901 HAL100 Halogen Lamp.
• 1 x 89 North Photofluor LM 75 Fluorescence Illuminator Lamp with PSU.
• 1 x Zeiss VP232-2 Power Supply.

• 1 x Lenovo ThinkPad T14s Gen 3 laptop running the AmScope camera software.

This Olympus BX51 WIF Fluorescence Microscope System was removed from a university lab where it was surplus to requirements.

The System unfortunately is largely untested as the lab was unable to part with the PC and software. They implied that it was in working order prior to having the PC removed as it was just surplus to requirements, but there are some parts missing.

Overall it is in good cosmetic condition but has general marks from use.

Details;

1 x Olympus Microscope

Model - BX51WIF

2 x Olympus Eye pieces - WH15X/14

2 x Objectives:-

Olympus LUMPlanFI/IR 40x/0.80 W ∞/0

Olympus Plan N 4x/0.10 ∞/-/FN22

Olympus Lamp

Model U-LH100IR

SN - 6F24822

There is no power supply for the lamp, we used one from another item (not included) to test the light which was working, tested with one of our slides and was able to focus.

Q Imaging optiMOS sCMOS camera

Cooled Mono 16 Bit

SN - Q41501

Lens - Olympus U-CMAD3/Olympus U-TV1X-2

Filter - HQ535/50 M 203616

There is no power supply cable for the camera.

Newport RG Breadboard Optics Table

Model - VH3036W-OPT

Dimensions - D76 W90 H80cm

Faraday Cage Dimensions - D78 W88 H90cm

The cage is in reasonable condition but has a few holes.

Table & Cage combined dimensions - D77 W90 H170cm

Scientifica Stage/Platform

Dimensions - D34.5 W60.5 H20.5cm

Power supply for Patch Clamp Micromanipulation System:-

Burleigh PCS-PS60

Powers on

2 x Burleigh PCS 5000 Series Controllers

SN - 0011431 & 0011420

2 x Burleigh PCS 5000 Series Micromanipulators

Burleigh TS - 5000 - 150

Other parts/accessories include:-

Unknown Part SN - 1270

Prior part

Hi-lo Nitrogen 10 Bar gas Regulator

Various small bits including crocodile clips and tubing

Nikon Eclipse Ni Microscope With Infinity 3 Camera Lab

This system was removed from a university where it was surplus to requirement.

The microscope is in good cosmetic condition and full working order.

It is fully operational with both software installed on the included PC.

Includes the following:

HP Desktop PC with Windows 10.

Software installed:

• Lumenera Infinity Analyze 7.1.1.66 imaging software.
• And MicroManger 2.03.

Infinity 3 camera with power supply cable.

Objectives:

• Nikon Microscope Objective - Plan Fluor 10X/0.30 Ph1 DLL ∞/0.17 WD 16.0
• Nikon Microscope Objective Plan Fluor 20X/0.50 DIC M/N2 ∞/0.17 WD 2.1
• Nikon Microscope Objective Plan Fluor 40X/0.75 Ph2 DLL ∞/0.17 WD 0.72

Eyepieces:

• 2 x Nikon C-W10xB/22

ZEISS PALM CombiSystem Axiovert 200M, XE120-XL,HV-D30P w/ Parts & Accessories

This was removed from a university lab where it was surplus to requirements.

The system powers up and the microscope is in good working order. We had some issues controlling the camera and the stage during testing, but this may be due to user error.

With the Palm RoboSoftware V4 we can control the following microscope features:

• Stage Y Axis movement
• Stage X Axis movement
• Objective Motor (able to select objective)
• Increase/Decrease Light
• Change Light Source
• Raise/Lower Objective

It is in excellent cosmetic condition with minor marks.

Included are the following;

Carl Zeiss Axiovert 200M

Model: Axiovert 200M

Serial#: 3820005950

Objectives fitted:

Zeiss Fluar 5x/0.25

Zeiss Fluar 10x/0.50

Zeiss LD Plan-Neoflaur 20x/0.40 Corr

Zeiss LD Plan-Neoflaur 40x/0.60 Corr

Zeiss EC Plan-Neoflaur 63x/1.25 Oil M27

Zeiss EC Plan-Neoflaur 100x/1,30 Oil

Eyepieces:

W-PL 10x/23 (Qty.2)

P.A.L.M Microlaser Technologies

Model: PALM CombiSystem

Serial#: CSC-01010

Date: 2007

Fujitsu Siemens Celsius R630 PC, Fujitsu Siemens SCIENVIEW B17-2 C CI Monitor (QTY.2) Fujitsu Siemens Keyboard, Mouse

Model: Celsius R630

Serial#: YKFU009307

Both Monitors, PC, Keyboard and Mouse are in good cosmetic condition and power on with no issue.

PC has the following software installed:

Palm RoboSoftware V4

Hitachi HV-D30 Camera

Model: HV-D30P

Serial#: 0675280

Laser Quantum LD3000 power supply

Model: Forte

Serial#: 02165

p

Zeiss CryLaS FTSS 355-50

Serial#: B594C279

Item powers on and is in full working order.

Communicates with control panel and microscope.

EXFO X-Cite Series 120

Model: XE120-XL

Serial#: 0570

Item is in good cosmetic condition.

Item powers on with light source in full working order.

All items listed above are sat on a Melles Griot Optical Table with PALM CombiSystem being fixed to it.

Measurements and weight of Melles Griot Optical Table are as follows:

Dx120Wx90Hx77cm

Weight:

Additional Parts & Accessories:

Zeiss AdhesiveCap 500 Clear

PALM MembraneSlides

PALM CombiSystem C User Manuals

PALM DishHolder 50 C

PALM MultiCap Insert 8c

PALM MultiCap Collector D 8C (Qty.2)

PALM CollectorSet SingleTube II 500

PALM CombiSystem User manual (Qty.2)

PALM RoboSoftware Software Guide (Qty.2)

Laser Quantum Forte Operating Manual

PALM MicroBeam Technical Information

Zeiss Axiovert 200 Operating Manual

Zeiss DuplexDish 50 Sterile Packed (Qty.6)

LumoxTM Dish 50 Hydrophilic, Sterile (Qty.5)

Zeiss MembraneSlide 1.0 Pen

X-Cite In Control Series 120 User's Guide

Zeiss PALM RoboSoftware CD

PALM MicroLaser System RoboSoftware 4.0 CD

Fujitsu Siemens Product Recovery CD

Carl Zeiss 29 Software Release 4.6

Zeiss Axiovert 200 M/Mat Floppy Disc

3-CCD Color Camera Model HV-D30 Operating Manual

Fujitsu Siemens Celsius Drivers & Utilities CD

Scenview B17-2 CI / B19-2 CI

Oxford Instruments INCAx-Act Energy Dispersive Spectrometer System

This system was removed from a university where it was surplus to requirement.

It powers on and is in good cosmetic condition, we are unable to test it further at our facility.

It was removed from a Philips XL30 SEM TMP system.

Includes:

• INCAx-act
• Model: 51-ADD0082
• Sensor: 51-1385-046

• INCA MICSF+
• ASSY: 51-G-1100-149

• INCA x-stream 2
• ASSY: 51-G-1100-131
• Unit has been powered up with the included PSU.

• 4 x PCI Interface Cards
• Presumed to have been removed from the controlling PC, includes various corresponding cables.

• Manual & Software Materials
• Oxford Instruments 'The Principles and Practice of X-ray Microanalysis' CD Rom Discs.
• INCA Binder with INCA Install Media Issue 5, The Microanalysis Suite Discs 1 & 2, Keys & Drivers, and 2 x USB System Recovery Pen Drives.

Applied Imaging Genetix Ariol SL-50 Vision BioSystems Olympus BX-61 Microscope

This was removed from a university lab where it was surplus to requirements.

The item is in a fairly good used cosmetic condition.

It appears to have some errors. Firstly the BX-UCB controller is showing an Error with CDT, which is the U-UCD8A turret. When switched on the turret makes a horrible noise, sounds like the motor is possibly stuck. We managed to clear the error by connecting the turret from another BX61 we have in stock, but it was removed after testing.

System includes the following:-

Vision BioSysytems

Model - SL50

SN - 0220229

Powers on

Microscope & Fitted Parts:-

Olympus BX61 Microscope

Model - BX61TRF

SN - 8K25329

Olympus Camera

Model - U-CMAD3

U-TV1X-2

Prior Stage

Model - H101AIBX

SN - 70177

Olympus Lamp

Model - U-LH100-3

SN - 8H23231

EXFO Collimating Adaptor

810-00032

SN - DH0583

2 x Olympus Eye Pieces - WHN10X-H/22

Olympus Objectives:-

UPlanFL N 10x/0.30 ∞/-/FN26.5

MPlanFL N 5x/0.15 ∞/-/FN26.5

UPlanFL N 60x/0.90 ∞/0.11-0.23/FN26.5

UPlanFL N 20x/0.50 ∞/0.17/FN26.5

UPlanFL N 40x/0.75 ∞/0.17/FN26.5

PlanApo N 1.25x/0.04 ∞/-/FN26.5

Other Units:-

Olympus Microscope Controller

Model - BX-UCB

SN - 8E14044

Powers on

Olympus Hand Switch

Model - U-HSTR2

SN - 8K22255

EXFO X-Cite Series 120PC Q Light Source

Model - XI120PC-Q

SN - XI120PC-Q-0283

Powers on

Prior Proscan II

Model - H30XYZ2AP

SN - 08439

Powers on

USB Joystick Controller (No Brand or Serial numbers)

PC Parts/Software:-

HP Applied Imaging PC

HP 24" Monitor

HP Keyboard

Dell Mouse

Applied Imaging Ariol 3.3 CD with Installation Instructions

USB Dongle

Ariol 3.4 Official Release Copied Disc

2 x Panasonic DVD-RAM Back up Discs

Box of various PC cables & IEC leads

Datalogic Gryphon Barcode Scanner & 2 Rolls of Barcodes

Manuals/Guides:-

Genetix Ariol User Manual - Scan, Entry, Review

Genetix Ariol SL-50 Installation

X-Cite Series 120PC Q User Guide

Olympus BX-UCB U-HSTR2 Instructions

Olympus Motorized Reflected Fluorescence System Instructions

Olympus BX61 Instructions

Olympus Camera Adaptor System Instructions

Olympus Motorized Revolving Nosepiece Instructions

Other Parts/Accessories:-

Applied Imaging Calibration Slide A

3 x Chroma Cases of filters

Nikon BE Plan 100x /1.25 Oil ∞/0.17 WD0.14 Objective

5 x Spare Slide Trays

ISI ABT Scanning Electron Microscope (SEM) ABT-55

This was removed from a university lab where it was surplus to requirements. We are told it was in working order prior to being put into storage some time ago

Included are;

ISA ABT 55 Main Control Unit

With 25cm CRT monitor

Control desk with all control switches and buttons

Microscope ABT 55 Unit

Serial No. K244149

Year 1989

Controls for vacuum system, not included

ETP Sempra Robison Detector Head and Control Module

Model PSM-11-4

Serial No. 524

The main units were not powered up due to no plug on the main power supply unit, it was previously hard wired.

The Robinson Detector unit powered on and displayed readiness lights.

Accessories:

5 x used spare copper columns

4 x small aluminium fitting plates

Operators Manual

4 x 15 amp fuses

Filament cartridge

Olympus BX-61TRF Microscope System

This system was removed from a university lab where it was surplus to requirements.

All components are in good used cosmetic condition and power on.

This system has been professionally serviced, the full service report is available on request.

The system consists of the following components:

• Microscope Base: Olympus BX-61TRF
• Olympus U-CMAD3 Camera Adapter
• Olympus U-TV1X2 Camera Adapter
• Olympus U-TR30-2 Trinocular Head
• Lumen Dynamics 810-00032X X-Cite Adapter
• Olympus U-SVRB-4 Manual Stage
• Olympus U-HLDT-4 Slide Holder
• Olympus U-UCD8A Condenser
• Olympus U-LH100L-3 Lamp

• Controllers and Power Supply:
• Olympus BX-UCB PSU/Controller
• Olympus U-HSTR2 Handset Controller
• X-Cite 120Q with EXFO Lightpipe
• 2 x Control Cables

Objectives Included:

• Olympus UPlan FL N 10x/0.30 ∞/-/FN26.5
• Olympus UPlan FL N 20x/0.50 ∞/0.17/FN26.5
• Olympus UPlan FL N 40x/0.60 ∞/C-2/FN22
• Olympus UPlan APo 40x/1.00 Oil Iris ∞/-
• Olympus UPlan FL N 40x/1.30 Oil ∞/0.17/FN26.5

Eyepieces:

• 2 x Olympus WH15X/14

This PALM Laser Microscope Microlaser MicroBeam Zeiss Axiovert 200M P.A.L.M was removed from a university lab where it was surplus to requirements.

The unit powers up and has all motorized and mechanical elements in good working order. It is in good cosmetic condition with only minor marks from use.

Zeiss Axiovert 200M

Model: Axiovert 200M

Serial#: 3820003116

There are 3 x Objectives included, and they are as follows;

Zeiss FLUAR

5x/0.25 ∞/0.17

Oil damaged as shown.

Zeiss FLUAR

10x/0,50 ∞/0,17

Good cosmetic condition.

Eyepieces:

Zeiss W-Pl 10x/23

All additional items included:

PALM Microlaser Technologies MicroBeam

Model: MicroBeam

Serial#: MB03216

Items in good cosmetic condition.

Untested.

Hitachi HV-D30P

Serial#: 0411529

Untested due to not having the cables required.

This Flir Systems ThermaCam SC500 194 780 was removed from a university lab where it was surplus to requirements.

The unit powers up and is in good cosmetic condition minor with marks from use, we are unable to test it further at our facility.

Included are the following:

Flir Systems PC Card Interface

P/N: 194 240

S/N: 2030068

HiTRON 13.5 volt Power Supply

M/N: HES61-11B

S/N: 0165

Flir Systems Break Out Box

P/N: 194 257

S/N: 3300066

Zeiss Axio Vert.A1 FL Inverted Microscope

This system was removed from a university lab where it was surplus to requirements.

The microscope is in very clean cosmetic condition. Four 27mm to RMS adapters have been fitted, allowing the use of standard RMS objectives. The microscope has been tested with an objective from stock and works as expected, though no objectives are currently fitted.

The instrument is configured as follows:

• 1 x Microscope stand Axio Vert.A1 FL (431030-9010-000)
• Nosepiece 2xH / 3xHDIC M27 and carrier for transmitted-light illumination
• Reflector modules: DAPI, FITC, TRITC, empty

• 1 x LD condenser 0.55 for H Ph PlasDIC DIC (424228-9030-000)
• Position 1: empty
• Position 2: 424228-9060 0.05T Neutral density filter 0.05
• Position 3: 426717-9170 Ph1/0.55 Phase stop Ph1/0.55
• Position 4: 426717-9180 Ph2/0.55 Phase stop Ph2/0.55
• Position 5: empty

• 1 x Illuminator LED for Axio Vert transmitted light (423004-9020-000)

• 1 x Stop slider A 14x40mm with aperture/luminous field diaphragm (423730-9151-000)

• 1 x Binocular tube 45º/23 (425523-9000-000) with 2 x 444036-9000 eyepieces PI 10x/23

• 1 x Mirror 100%, 26x36mm (452531-0001-010) with intermediate phototube H=50mm, left port (425146-9030-000)

• 1 x Camera adapter 60N-C 2/3" 0.5x (426112)

• 1 x Ergo Intermediate piece H=50mm for optimization of viewing height (425146-9040-00)

• 1 x Specimen stage 232x230mm with hardcoat anodized surface (432037-9000-000)

• Object guide M, 130x85mm, for Axio Vert (432333-9040-000)

• 1 x QImaging QIClick Camera (01-QIClick-R-F-CLR-12), Colour 12 Bit, Firewire operation

Zeiss Axioplan 2 Microscope + LSM 510 Laser Scanning System

This system was removed from a university lab where it was surplus to requirements.

The microscope is in working order, but we have not tested the laser due to safety restrictions at our site.

There are no objectives fitted.

Items included are:

-Zeiss LSM Control S/N- 000260

-Hal 100 Lamp

-Lasos Lasertechnic GMBH S/N- 04041136 M/N- 9600-07

-Zeiss HBO 100W

-Zeiss HBO 100W/2

-Zeiss Lasermodul UV

-Fujitsu Siemans mouse

-Relevant manuals and guides

-Connection cables

-Comms PCi Cards & Dongle (non USB)

Zeiss Axiovert 200M Fluorescence Microscope

This system was removed from a university lab where it was surplus to requirement.

It is in good cosmetic condition and in full working order, however we recommend it be cleaned internally and be serviced once purchased.

This microscope consists of the following:-

• Zeiss Axiovert 200M Body

Model: 1005-820

• HAL 100 Halogen Lamp

Model: 44 72 19 1039-685

• Carrier for Transmitted Light Illumination

Model: 1005-840

• LCD Display

Model: 1071-167

• Polarizer D (Rotatable)

Model: 1121-813

• LD Condenser 0.55

Positions: H, Ph1, Ph2, Ph3, DIC, DIC

Model: 1005-847 (DIC Prisms not fitted)

• Manual Stage with Universal Mounting Frame K

Frame Model: 451352

• 5-Position MOT Reflector Turret

Model: 1064-365

Filters:

• Fs 02
• Fs 10
• Fs 15 (1046.281)
• Fs 31 (1046.281)
• One unknown filter (slot shows as "empty" but contains a cube)

• HBO 100 Mercury Lamp

Model: 1007-980

• Includes FluoArc PSU (light in power switch does not work, but functionality unaffected).
• Model: 434-355
• (Run hours of the lamp are unknown.)

• Binocular Tube 45º/23

Model: 1005-827

• Fitted with W-Pl 10x/23 Eyepieces
• Model: 1016-758

• FL Incident-Light Equipment

Model: 1066-230

• Includes:
• Adjusting Aid for HBO (Model: 452369)
• 2 x Iris Stop Sliders (Model: 1062-360)

• Objective
• Zeiss Plan-NEOFLUAR 20x/0.50
• Model: 1004-072

JEOL JSM 840A  SEM Scanning Electron Microscope System

This was removed from a university lab where it was surplus to requirements.

The lab confirmed it was in working order prior to removal, but the control panel was removed and sold separately. It has not been tested at all at our facility but it is in good cosmetic condition with marks from use.

Included are;

Main unit:

1 x JEOL JSM-840A Scanning Microscope

Model: JSM-840A

Serial#: EP130077

Item has attached:

1 x Oxford Instruments 6605

Serial#: 09091-3390-339-521

Power Supply Unit:

JEOL JSM-840A Main Power CSL

Model: JSM-840A Main Power CSL

Serial#: EP130077-40

Also included:

JEOL Pump

Model: N/A

Serial#: N/A

Good cosmetic condition.

Lx36Wx24Hx50cm

JEOL JSM-840A User Manual

JEOL JSM-840A Service Case

This contains:

JEOL Extender MP001569-01

Various washers, fixings, screws etc.

Hitachi S4000 Microscope (SEM) Scanning Electron Microscope Lab

This system was removed from a university laboratory where it was surplus to requirements.

It is in good cosmetic condition. Unfortunately, we are unable to power it on or test it further on site.

According to the previous owner, this system was serviced until 2022 and was operational prior to decommissioning.

This Hitachi S3000H SEM Scanning Electron Microscope is being sold on behalf of a laboratory. It is surplus to requirements.

The lab informed us that it was working when last used.

The microscope is from 1998, has one SE2 Detector.

Included are the following;

Hitachi S3000H SEM Scanning Electron Microscope Lab

Model: S-3000H

Date: 9/8/12

Part#: 50E-G386

Serial#: 1014-30

System specifications

- 0.3 - 30kV acceleration voltage range

- 5 nm resolution at 25kV in variable pressure mode

- 150mm diameter maximum specimen size

- Dual-bias for low voltage signal noise

- Backscatter mode

Canatron Transformers EN 60742 Transformer

Model: EN 60742

Serial#: CT6699

Hitachi CM751ET Monitor

Model: CM751ET

Serial#: G8E008620

Hitachi CM751ET Monitor

Model: CM751ET

Serial#: T9A 012253

Hitachi S3000H SEM Control Panel

Serial#: 1014-30

Edwards Oil Mist Filter EMF20

Serial#: A 462 29 000

Hitachi Measure Function Setup Disk V 01-05

Serial#: 50E-5497

Hitachi SEM Data Manager Setup Disk V 01-05

Serial#: 50E-5502

Hitachi S-3000Series V 10-16 CD Disc 1 & 2

Serial#: 50E-8108

Hitachi PC-SEM Restore CD Disc 1 & 2

Serial#: 1014-30

Adaptec SCSI Select v2.57.4 Floppy Disk

Serial#: 1492920-00

Adaptec AVA-2915LP/2930LP v1.13 Floppy Disk

Serial#: 1495022-00JA

HP Operating System DVD

Serial#: 483886-B21

Contec Drivers Software COM Setup Disk v.1.8

Serial# LYBM994

HP Compaq Business PC Documentation and Diagnostics DVD

Serial#: 490849-B21

HP Operating System DVD

Serial#: 394378-002

HP Operating System DVD

Serial# 486467-B22

HP Restore Plus! DVD

Serial#: 481206-B25

Roxio Creator Business 10 DVD

Serial#: 498164-B21

S300H Printed Circuit Board

Model S-3000H SEM Instruction Manual

Serial#: 50E-9247-9

Hitachi S-Type Filaments

Date: 08.06.201

Lot#: 0490228080

Serial#: 777-0179

Zeiss Axioscop 2 Plus Microscope With FluoArc Power Supply Lab

This item was removed from a university where it was surplus to requirement.

Both the microscope and power supply are in good cosmetic condition and powered on. The previous client has stated that this microscope was in full working order when it was last used.

It has been tested with an in-house objective, which is not included.

Includes the following:

1 x Zeiss Axioscop 2 Plus Microscope

-2 x Carl Zeiss E Pl 10x / 20 Eyepieces

1 x Zeiss Fluoarc Microscope Light Source Power Supply Fluoarc/001.26B

1 x Zeiss HBO 100 1007-980 Illuminator Lamp Housing

1 x Zeiss HAL-100 100W 12v Illuminator Lamp Housing

This GE Healthcare IN Cell Analyzer 2000 Imaging System was removed from a university lab where it was surplus to requirements.

The unit powers on but has not been tested further. The lab Confirmed it was in full working order prior to collection.

It comes with an HP PC, Monitor & Keyboard which has a number of programmes installed including In Cell Analyzer Workstation 3.7.2

It is in good cosmetic condition with some marks from use.

Leica Microsystems Type - TCS SP2 Confocal Microscope System

This was removed from a university lab where it was surplus to requirements.

What is included is in good working order, but the system is not complete.

It is missing the following;

Table top

Cooling unit

Microscope isolation table

Camera

Flexi tube for prior unit.

Bulb for prior unit.

There may be more missing parts, but we are unable to confirm.

It is in good cosmetic condition with minor marks.

Included are;

Leica TCS SP2 Microscope

Model: RCS SP2

Serial#: 142400026

Attached to microscope:

Leica ∞/0.17/E HCX PL APO 40x/1.25-0.75 OIL CS

Leica ∞/-/C HC PL APO 20x/0.75

Leica ∞/0.17/E HC PL APO 10x/0.40 CS

2 x Eyepieces HC PLAN S 10x/22

Leica Condenser 0.53 S 23 (521500)

Leica C Mount Adaptor 0.5x : 1/2" = 16 (541511)

All other items included:

Prior Lumen200

Model: L200/C

Serial#: 70808

Ernst Leitz Wetzlar Gmbh

Type: 307-072.45

Hg 100 W Bulb

Leica Power Supply for DiodeLaser COH 405nm, 25mW

Part#: 1530910001 03

Leica DM R Manual

Leica Confocal Software

Leica TCS User Manual

Leica PC with Software installed.

Leica Dust cover for Microscope and PC.

Hamamatsu ORCA-Flash 4.0LT Plus Digital Camera C11440-42U30

This item was removed from a university laboratory where it was surplus to requirements.

The camera powers up and is in good used cosmetic condition.

It requires the following driver and software to run. (not included)

DCAM-API Driver

HCImage Software Suite

Includes:

• Power Supply Unit (PSU)
• USB 3.0 cable

Model: C11440-42U30

Gatan Mono CL SEM Detector Units with Princeton Pixis 100 Detector Camera

This system was removed from a university laboratory where it was surplus to requirements.

All units are in good cosmetic condition and power on, we are unable to conduct further testing at our facility.

The system comprises the following:

• Gratan Mono CL Detector Unit (Serial No. not present)
• Princeton Instruments Pixis 100 Detector Camera
• Model: 7515-0001
• Serial No.: 07040180003
• Princeton Instruments 12 Volt Power Supply
• Part No.: 4000-0052
• Serial No.: 04230594 0729
• Gatan Peltier Power Supply (Serial No. not present)
• Gatan Mono CL4 MRU (Manual Remote Unit) (Serial No. not present)
• Gatan 788 Digiscan II
• Model: 788.UK
• Serial No.: 08081302W0788
• Gatan PA4 Photo Amplifier (Serial No. not present)

Software Included:

• Microscopy Suite Ver 1.8 beta
• Microscopy Suite GMS 1.8.4
• System Response Files
• Stardock Mouselink
• Licenses Ver 1.6

Manuals Included:

• CD-R for Princeton Instruments Model 7515-0001
• Princeton Instruments Pixis user manual
• Mono CL4 operator's handbook

Additional Accessories:

• Mono CL4 cathodoluminescence mirror
• 39.5 cm detector connection shaft
• 7 data cables
• Gatan Digiscan differential converter
• 4 small blanking plates
• Gasket
• MCX-M to BNC-F adaptor (Part No. 6050-0540)

Nikon Eclipse TE300 Inverted Fluorescence Microscope System Lab

This was removed from a university lab where it was surplus to requirements.

This system is in good cosmetic condition with all included units in working order.

1 x Nikon Eclipse TE300 body fitted with:

1 x Nikon 065851 multi position binocular neck.

1 x Nikon manual stage.

1 x Nikon filter holder, no filters fitted.

1 x Nikon Condenser Turret fitted with 1 x LWD ∞ Ph3 & 1 x Blanking plate.

The other 3 blanking plates are missing.

1 x Nikon LWD 0.52

2 x Nikon CFI 10x/22 eyepieces.

1 x Nikon Plan Flour

20x/0.50

Ph1 DLL

Objective.

1 x Nikon LHS-H100P-1 Halogen 12v 100w Lamp.

1 x Nikon TE-PSE100 Power supply with control cable.

1 x Nikon LH-M100C-1 Mercury 100w Lamp. (Run hours not known, bulb will require replacement).

1 x Nikon C-SHG1 Power Supply. (Run time counter reset).

This Olympus Fluoview FV1000 System was removed from a university lab where it was surplus to requirements.

Included are;

1x Olympus Fluoview

Model FV1000

The unit is in good cosmetic condition, but the power cables were missing so it has not been tested.

The included PC powers up and has Olympus FV10-ASW Version 01.06.00.13 installed.

1x Olympus Transmitted Light Detector:

Model FV10-TD

The unit is in good cosmetic condition.

1x Olympus Control Box:

Model IX2 UCB

The unit powers on and is in good cosmetic condition.

1x Olympus Power Supply:

Model FV10-PSU

The unit powers on and is in good cosmetic condition.

1x FV10-PSU Key:

Model 1201

The unit is in good cosmetic condition.

1x Olympus Hand-switch:

Model U-HSTR2

The item powers on and is in a reasonable, used cosmetic condition.

1x Olympus Laser Diode Interface Controller:

Model FV10-LDIF

The unit is in good cosmetic condition. The PSU is missing.

1x Olympus Power Supply:

Model U-RFL-T200

Life Time: 3667 hours

The unit powers on and is in good cosmetic condition.

It is not known if the Burner has been replaced after 200 hours.

1x Olympus Mercury Light Source:

Model U-LH100G

The unit powers on and is in good cosmetic condition. The Lamp is working.

1x Olympus Light Source Stand

Model FV10-FIR

The unit is in good cosmetic condition. There are some scuffs and scratches from general use.

1x Olympus Power Supply:

Model FV5-LDPSU

Running hours: 79335.3

The unit powers on and is in good cosmetic condition.

I was unable to connect the head to the power supply as there is no cable that comes with the two units.

1x FV5-LDPSU Olympus Power Supply Key:

Model 1201

The unit is snapped. However, FV10-PSU key is the same model and fits the barrel of the FV5-LDPSU Olympus power supply.

1x Olympus Laser Head

Model LD405

The unit is in good cosmetic condition.

I was unable to connect the head to the power supply as there is no cable that comes with the two units, I could not test whether the laser head is responsive to the power supply.

1x IW-R3000N Rack Mountable Server Chassis

The unit powers on and is in good cosmetic condition.

Accessories:

1x Olympus objective correction cap

Model CAP-G0.5 ± 0.5

The unit is in good cosmetic condition

1x Olympus Laser safety shutter

Model F10-SHAUX

The unit is in good cosmetic condition.

1x Olympus Goose neck fibre optic light pipes

Model LGS3F1200UV

The unit is in good cosmetic condition.

Spacers:

2x L3cm xW3cm xH0.5cm

2x L4cm x W4cm x H0.5cm

The units are in good cosmetic condition.

Misc Accessories:

1x IW-R3000N Rack Mountable Server Chassis User manual V2.1

1x Microsoft Windows 2000 XP professional Inst/uninst CD

1x Belkin Serial Adaptor

1x RCA Phono male to male cable (sealed)

1x SATA Cable (C13214-001 FOXCON 0550)

1x 9 PIN S -Video to 3 RCA RGB TV HDTV adaptor cable

1x ATX 4 Pin Male to 8 Pin Female EPS power cable cord adaptor

1x RCA Female to mini DIN 8-PIN connector (sealed)

1x VGA to DVI connector (sealed)

Installation discs:

2x Belkin USB Adaptor Installation

1x Intel Express installer

1x Sapphire installation driver

1x mini disc

Zeiss Axioplan 2 Fluorescence Microscope w/ 4 Objectives Lab

This item was removed from a university where it was surplus to requirement.

The unit appears to be functioning well and can also be controlled via the free MicroManager software.

It is in good cosmetic condition.

It does feature the following:

2x Eyepieces PL 10 x 25

P/N: 44 40 34

2x Zeiss Plan-NEOFLUAR 40x/0.75 ∞/0.17

P/N: 44 03 51

P/N 44 03 50

1x Zeiss FLUAR 100x/1.30 oil ∞/0.17

P/N: 44 02 85

1x Zeiss Plan-NEOFLUAR 63x/1.25 oil ∞/0.17

P/N: 44 04 60

1x Carl Zeiss HAL 100 12v 100w lamp house

P/N: 1039-685

1x Zeiss Reflector Turret with 6 filters

1x FITC

1x TRITC

1x YFP

1x CFP

1x Cy5

1x DAPI

Leica DMR Type 020-525.735 Fluorescence Microscope Lab

This item was removed from a university where it was surplus to requirement.

It is in good cosmetic condition and powers on with the bottom-mounted lamp in good working order.

We are unable to test the top-mounted lamp as the required power supply is not included.

Includes with the microscope are the following:

• Leica MPS 60 Camera
• Leica ∞/0.17 C Plan 100x/1.25 Oil Objective
• Leica ∞/-/A N Plan 5x/0.12 Objective
• 504058 Leica Illuminator
• Leica 807-072.057 Lamp Module (damaged)
• Box of misc tools and accessories

Nikon Eclipse TE300 Inverted Fluorescence Microscope

This item was removed from a university where it was surplus to requirements.

The microscope powers on and produced a clear slide image when tested with an in-house objective (not included).

It is in good cosmetic condition, however, the protective visor has snapped off. This does not affect its functionality.

Included:

• Nikon Power Supply (Model: TE-PSE30, S/N: 4010214)
• Q Imaging QI Click Camera (Model: 01-QIClick-F-M-12, S/N: Q28643)
• 2 x CFI 10X/22 Eyepieces

Specifications:

• Model: TE300
• S/N: 533589

Zeiss Axioskop 2 System Power Supply

This system was removed from a university lab where it was surplus to requirements.

All included units power on and are in good cosmetic condition.

The previous client has stated this system was in full working order prior to removal.

The system includes the following Zeiss objectives, all of which are producing clear images and are in good condition with no scratches:

• Zeiss Plan-NEOFLUAR 20X/0.50 (1004-072)
• Zeiss Epiplan 10X/0.20 HD (44 29 34)
• Zeiss Plan-NEOFLUAR 40X/0.75 (44 03 50)
• Zeiss Epiplan 50X/0.70 HD (44 29 54)

Additional components:

• Jena GmbH ebq 100 Isolated Power Supply (Model: ebq 100 isolated-z/101 26f, S/N: M 47415479)
• 2 x HAL 100 Lamps (1039-685, 44 72 19)
• 1 x HBO 100 Lamp 1007-980
• Imagingsource DFK 41AFO2 Camera
• 2 x Zeiss W-Pl 10x/23 Eyepieces (45 50 43)

Please note, there is no mercury bulb included.

Zeiss AxioSkop 2  Microscope w/ 3 x Objectives 20/40/100x Lab

This item was removed from a university laboratory where it was surplus to requirements.

It powers on and is in good used condition.

The microscope has been tested using in-house slides and is in good working order.  (test slide not included)

AxioSkop 2 Main Body

• Zeiss 45 23 44 Trinocular head with camera port
• Zeiss 45 21 87 Filter Cube fitted
• Zeiss 45 35 60 Specimen/Object Guide
• Zeiss 45 35 50 Rotary Stage
• Zeiss 44 54 39 Condenser
• Zeiss 44 72 19 HAL 100 Halogen Lamp

• Objectives:
• AmScope 20/0.40, 160/0.17 (Brand New)
• AmScope 40/0.65, 160/0.17 (Brand New)
• Zeiss Plan-NEOFLUAR 100x/1.30 Oil, ∞/0.17, 44 04 80

• Eyepieces:
• 2 x Zeiss 45 50 43 W-Pl 10x/23 Eyepieces
